Avant standard ticketing kiosk

The Avant Kiosk Series

Contemporary Design & Sophisticated Transaction Capability

Overview

The Avant standard kiosk is a highly configurable and compact platform designed to house a wide variety of high-demand transaction components. It can be deployed as a countertop, a pedestal, or with cash / coin component shroud as the base. The user interface is presented in a 21.5” zero bezel projective capacitive (PCAP) touchscreen, providing brilliant resolution and precision touch. It features hinged access doors with distinct component integration for simple service and maintenance. As with many of KIOSK’s newer models, optional programmable LED lighting provides an attractive and modern accent to draw user attention.

This platform can be configured for several self-service applications including order entry, ticketing, check-in, queuing, and more. The upper LCD panel houses payment and scanning devices, receipt printer, an optional camera and biometric identification components. The lower cabinet can house the PC, bill acceptor / dispenser / recycler, service keyboard, and power supply. The Avant series is an excellent platform to house components that accommodate all payment types (cash, coin, card, NFC), and extends the benefit of self-service across all consumers.

The Avant is an ADA compliant design with secure and tested components.

Options & Specs

Base Model Includes

  • Durable Powder Coated Steel Enclosure
  • Premier PC Brands / Application-appropriate Model Options
  • Dual Amplified Speakers
  • 21.5” LCD Display
  • Touch Screen Interface

Optional Components

  • Bar Code Scanner
  • Swipe ID Scanner
  • Credit Card Reader / NFC payment device
  • Receipt Printer
  • Camera
  • Proximity sensor
  • Privacy Screen
  • WiFi Capability
  • Programmable Accent LED Lighting

Enclosure Dimensions

Pedestal Configuration

  • 53” High, 22″ Wide, 24” Deep at Base Plate
  • Base plate: 24″ Wide, 24″ Deep

Countertop Configuration

  • 20” High, 22″ Wide, 16” Deep
  • Assumes 34″ counter height for ADA Compliance

Cash and Coin Shroud Configuration

  • 54” High, 27″ Wide, 23” Deep
  • No Base plate
